All prices advertised are cash price.
Revolt 48″ Kawasaki FX730 23.5HP – Call for pricing
Revolt 54″ Kawasaki FX850 27HP – Call for pricing
Revolt 61″ Kawasaki FX850 27HP – Call for pricing
Revolt 54″ Kawasaki EVO781 EFI 31HP – Call for pricing
Revolt 61″ Kawasaki EVO781 EFI 31HP – Call for pricing
Revolt 54″ Vanguard EFI 28HP – Call for pricing
Revolt 61″ Vanguard EFI 28HP – Call for pricing
The Commercial Stand-On Zero-Turn
Features
22 – 31 Horsepower (Depending on Engine Option)
Dual Hydro-Gear Performance Integrated Drive Systems
Curved I-Beam Front Rail with Lower Center of Gravity
3/16″ (7-Gauge) All-Steel Fabricated Deck with Reinforced Edges
Quick-Access Panel for Drive and Belt Maintenance
Electric PTO (Blade Engagement)
Patented Adjustable Rubber Suspension Riding Platform
Additional Features
3/8″ Steel Front Forks with 3½″ Trail for Smooth Directional Control
Improved Variable Deck Lift Adjustment System
Removable Quick-Access Panel for Battery, Control Arm, and Hydro-Tank Maintenance
PEER Maintenance-Free Spindles
Three-Position Speed Control
Ergonomic Thigh Pad with Flip-Up Access
No-Flat Front Tires
Factory-Installed Striping Kit
Available in 36″, 48″, 54″, and 61″ Deck Widths
Built Proudly in the USA
Specifications
Engine Options:
• Kawasaki FX691V – 726 cc (≈ 22 HP, Air-Cooled)
• Kawasaki FX730V – 726 cc (≈ 23.5 HP, Air-Cooled)
• Kawasaki FX850V – 852 cc (≈ 27 HP, Air-Cooled)
• Kawasaki FX781V EVO EFI – 822 cc (≈ 31 HP, EFI)
• Vanguard EFI – 810 cc (≈ 28 HP, Air-Cooled)
Number of Cylinders: 2 (Air-Cooled V-Twin)
Fuel Tank (gal): 6.5 (Unleaded Gasoline)
Transmission:
• 36″ – Dual Hydro-Gear ZT-3100 10cc Integrated Transaxles
• 48″ / 54″ / 61″ – Dual Hydro-Gear ZT-3400 12cc Integrated Transaxles
Drive Type: Hydrostatic
Ground Speed (Forward): Up to 9 MPH
Cutting Widths: 36″ / 48″ / 54″ / 61″
Cutting Height Range: 2″ – 5″
Deck Construction: 3/16″ (7-Gauge) Fabricated Steel Deck with Reinforced Edges
Lift System: Manual Lift with Improved Variable Deck Adjustment
Front Tires: 13 × 6.5-6 Smooth (No-Flat Design)
Rear Tires:
• 36″ – 21 × 7-10 Reaper®
• 48″ / 54″ – 23 × 9-12 Reaper®
• 61″ – 23 × 11-12 Reaper®
Overall Length: 63″
Overall Height: 48″
Overall Width (Chute Up / Down):
• 36″ – 38.5″ / 50.5″
• 48″ – 50.5″ / 62.5″
• 54″ – 56.5″ / 68.5″
• 61″ – 63.5″ / 75.5″
Weight:
• 36″ – 805 lbs
• 48″ – 930 lbs
• 54″ – 980 lbs
• 61″ – 1,040 lbs
Frame: 1.5″ × 3″ Heavy-Gauge All-Steel, All-Welded
Spindles: PEER Maintenance-Free
Platform: Adjustable Rubber Suspension Riding Platform
PTO Type: Electric Clutch
Fuel Type: Unleaded Gasoline
Includes Utilitough 6×10 Utility Trailer for easy transport of mower and attachments.
